Visio KD-D0414D - Standalone DVR H.264 DVRs Full D1 2U

Chargement...

-52%

Standalone DVR H.264 DVRs Full D1 2U KD-D0414D

Quantité

Ajouter au panier

Ajouter à ma sélection

Prix Normal : 11 838,96 Dh HT

Votre Prix :5 637,60 Dh HT

6 765,12 Dh TTC

Economie : 6 201,36 Dh - 52%

standalone DVR Full D1 2U with high performance best for high-end market H.264 compression algorithm ideal for standalone DVR Realtime live display up to 16 cameras with 720P high definition 400/480 fps recording for 4CIF Dual encoding streams support

Disponibilité : Non disponible

Evaluation :

Evaluer ce produit.

Description
Avis des clients

FICHE TECHNIQUE

Description du produit
Model	KD-D0414D
System
Main Processor	High performance embedded microprocessor
Operating System	Embedded LINUX
System Resources	Pentaplex function: live, recording, playback, backup & remote access
User Interface	GUI, on-screen menu tips
Control Device	Front panel, USB mouse, keyboard, IR remote control, network keyboard
Input Method	Numeral/Character/Denotation
System Status	HDD status, data stream statistics, log record, bios version, on-line user etc.
Video
Video Input	4/8/16 channel, BNC, 1.0Vp-p, 75omh, looping
Video Output	1 channel TV output, BNC, 1.0Vp- p, 75omh, 1 VGA output, 1 HDMI output
Video Standards	PAL(625Line, 50f/s), NTSC(525Line, 60f/s)
Video Compression	H.264
Video Resolution	Format D1(4CIF) CIF QCIF	NTSC 704 X 480 352 X 240 176 X 120	PAL 704 X 576 352 X 288 176 X 144
Video Recording	4CIF/CIF/QCIF: PAL 1f/s-25f/s NTSC 1f/s-30f/s; Dual encoding streams supported;
Video Display Split	Full and multiple screen display, 1 / 4 / 9 / 16
Tour Display	Support
Image Quality	1~6 level(level 6 is the best)
Privacy Masking	4 self-defined four-sided zones for privacy masking for each camera
Camera Lock	Camera locked for users
Camera Adjustment	Adjust color according to different time period
Video Information	Camera title, time, video loss, camera lock, motion detection, recording
TV Output Adjustment	Adjust TV output color & display zone
Audio
Audio Input	4/8/16 channel, BNC, 200-2800mV, 30KO
Bidirectional Talk Input	1 channel, BNC, 200-2800mV, 30KO
Audio Output	1 channel, BNC, 200-3000mv, 5KO
Audio Compression	G.711
Video Detection & Alarm
Motion Detection	Zones: 396 (22*18) detection zones Sensitivity: 1~6 (level 6 is highest) Trigger recording, PTZ movement, tour, alarm, email, matrix output
Video Loss	Trigger recording, PTZ movement, tour, alarm, email, matrix output
Camera Blank	Trigger recording, PTZ movement, tour, alarm, email, matrix output
Alarm Input	16/16/16 channel, programmable, ground, manual open/closed Trigger recording, PTZ movement, tour, alarm, email, matrix output
Relay output	6/6/6 channel, 30VDC, 1A, NO/NC, form-C
Hard Disk
Hard Disk	8 SATA ports, 8 HDDs supported, eSATA port
Space Occupation	Audio: 14.4MB/H Video: 56~500MB/H
HDD Management	Hard disk hibernation technology, HDD faulty alarm & Raid(Redundancy)
Record, Playback & Backup
Recording Mode	Manual, continuous, video detection (including motion detection, camera blank, video loss), Alarm
Recording Priority	Manual •Alarm •Video Detection •Continuous
Recording Interval	1 to 120 minutes (default: 60 minutes), Pre-record up to 30 seconds, Post-record up to 5 minutes
Overwrite Mode	Support
Search Mode	Time/Date, Alarm, Motion Detection & exact search (accurate to second)
Playback	16 channel playback simultaneously, pause, stop, rewind, fast play, slow play, next file, previous file, next camera, previous camera, full screen, repeat, shuffle, backup selection
Digital Zoom	Selected zone can zoom into full screen during playback
Backup Mode	Flash disk/ USB HDD/ USB CD/DVD-RW/ built-in SATA burner/ Network download
Network
Interface	RJ-45 Port (10/100M)
Network Functions	TCP/IP, UDP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Email, Alarm Server
Remote operation	Monitor, PTZ control, playback, system setting, file download, log information
Auxiliary Interface
USB Interface	2 ports, 1 for mouse control, 1 for backup
RS232	keyboard, PC communication
RS485	PTZ control
Environmental
Power Supply	220V 50Hz / 110V 60Hz
Power consumption	25W/30W/40W
Working Temperature	-10°C~+55°C
Working Humidity	10%~90%
Atmosphere Pressure	86kpa~106kpa
Dimension	1.5U, 440mmx460mmx89mm (WDH)
Weight	6.5KG(without HDD)
Mounting	Desktop or rack
