Fiche technique

MJPEG compression

Pan/tilt, day/night 12IR (10m), 6mm and board
Wireless network, supports to connect with USB dongle as wireless device
RS232 interface, supports wireless smoke detector and wireless security detector
USB hub interface, supports USB flash disk record (up to 8GB) and supports USB hard disk (120GB)
Function network surveillance long distance/local video recording and screen shot
Security different access levels, password protection and IP-address self-management
Alarm RS232 interface, support wireless smoke detector and wireless security detector
Motion detect and send alarm pictures to email
Supports up to 30 remote viewers per camera

SPECIFICATIONS

Image sensor: 1/3-inch CMOS
Resolution:
      380K pixels
      VGA: 640 x 480 pixels
      CIF: 352 x 288 pixels
Pan/tilt and lens pan, +/-150 (0 to 320 degrees)
Tilt: +/-30 (0 to 180 degrees) 6mm fixed lens
Lens angle: 60 degrees
IR and distance 12 pieces infrared lights: 10m
Minimum illumination: 5.0Lux at F2.0
Signal system: PAL/NTSC
Network protocols: TCP/IP, HTTP, ARP, RARP, ICMP, DHCP, FIP, SMTP and PPPOE
Network ports: RJ45, 10/100M Ethernet LAN
Wireless protocol: IEEE802.11b/g
TX distance indoor: can be 50m, while outdoor can be 100m (it depends on the environment)
RF power: 18 to 19dBm (11g) and 14 to 18dBm (11g)
Browser: Microsoft Windows 2000, XP or high version, Netscape 4.5 or high version
Video compression format: MJPEG compression
Frame rate: 25fps
Input: 1 to 2 channels
Output: 1 to 2 channels
Lens mount: C/CS mount lens
Whit balance/BLC: auto
Record support USB flash disk record (up to 2GB), supports USB hard disk (80GB)
Extension supports USB hub
Power supply: 5.3V DC/1A, 100 to 240V
